Maximize space and performance in your OEM equipment with our compact 360-Degree Actuation Valve. Designed specifically for integration into skid-mounted systems, modular units, and tight machinery footprints, this valve delivers full-performance sealing in a minimized envelope. Its innovative design incorporates a streamlined actuation valve profile and standardized mounting pads, allowing for direct, secure attachment of pneumatic or electric actuators without complex linkages.

The core technology remains our reliable 360-degree ball rotation, providing a positive shut-off for liquids and gases in compact cooling loops, lubrication systems, hydraulic power units, and instrumentation panels. Manufactured from high-grade stainless steel or carbon steel, this rotary valve withstands the vibrations and space constraints typical of packaged systems. The low-torque, quarter-turn operation ensures swift and dependable control, crucial for automated sequences.

By choosing this valve, OEM designers gain a reliable, leak-proof component that simplifies assembly, reduces overall skid dimensions, and enhances the reliability and value of the final packaged system.

Key Features

Space-saving design optimized for integration into skid-mounted systems and compact machinery
Standardized ISO mounting pad allows for direct, secure actuator attachment
Reliable 360-degree sealing performance ensures leak-free operation in confined spaces
Low-torque quarter-turn operation reduces actuator size and cost requirements
Available in a variety of materials and port connections (NPT, SAE, flange) for flexible OEM design

Application Example

This valve is integrated into a modular hydraulic power unit (HPU) for a mobile crane. Mounted directly on the reservoir outlet, its compact form factor saves crucial space. The integrated pneumatic actuator allows the central control system to quickly open or close the valve to isolate sections of the hydraulic circuit for maintenance or safety checks, all relying on its dependable 360-degree seal to prevent oil leaks.

Manufacturing Process

Produced in high-volume, automated cells with a focus on dimensional consistency and just-in-time delivery for OEM partners. Laser etching is used for permanent marking. A statistical process control (SPC) system ensures every valve meets the precise specifications required for drop-in assembly on customer skids.

Packaging & Shipping

For OEM partners, valves are packaged in reusable, stackable totes or custom-sized boxes for efficient handling on assembly lines. They are often shipped in bulk quantities on pallets with barcoded labels matching the customer's part numbering system for seamless integration into their inventory.

Frequently Asked Questions

How does the integrated mounting pad benefit our OEM assembly process?

The integrated pad eliminates the need for separate mounting brackets or linkages. Your actuator bolts directly onto the valve, slashing assembly time, reducing potential leak points, and ensuring perfect alignment every time.

Is the 360-degree sealing as effective in a compact valve design?

Absolutely. The full-rotation sealing principle is inherent to the core design. The compact size is achieved through optimized body geometry, not by compromising the critical ball and seat interface, which remains full-profile.

Can we order these valves with custom port threads or configurations?

Yes. As a dedicated OEM supplier, we frequently provide custom machining for port connections, special materials, or unique finishes to match your specific skid-mounted system requirements.

What is the operating pressure range for these compact valves?

Our standard compact series is rated for working pressures up to 600 PSI, with high-pressure variants available. The quarter-turn design inherently provides excellent pressure containment.

Do you offer just the valve body without an actuator for our own sourcing?

Yes. We can supply the actuation valve as a manual unit (with lever or handwheel) or as a prepared automation-ready unit with the mounting pad, ready for you to install your preferred brand of actuator.
